Rixin Aspect 27.5+ Bike

The Rixin Aspect 27.5+ Bike was built from the ground up for wheelies, cruising and all-around bike life. The lightweight 6061 aluminum frame uses wheelie-friendly geometry, while a full chromoly fork and Theory Turnstyle cassette hub with a 14mm rear axle keep it ready for hard riding.

Big 27.5 x 3.0" tires give it plenty of grip and cushion, and Shimano hydraulic disc brakes front and rear provide serious stopping power. Sealed bearings, a full lineup of Theory parts, bottle-cage mounts and internal routing for a dropper-post cable round out a bike that is ready to ride and easy to upgrade.

Recommended rider height: 5'4" and taller

Geometry

• Top tube: 23.5"
• Head tube angle: 71°
• Seat tube angle: 71°
• Standover: 14.3"
• Chainstay: 17.6" slammed
• Fork offset: 30mm

Specs

• Frame: 6061 aluminum with bottle-cage mounts and dropper-post cable entry
• Fork: 100% 4130 chromoly with tapered legs, 30mm offset
• Bars: Hi-Ten, 5" rise x 30" wide
• Grips: Theory Data flanged, 150mm, with Theory bar ends
• Stem: Theory Bond top load, 50mm
• Headset: Theory sealed integrated
• Brake levers: Shimano MT201 hydraulic disc
• Brakes: Shimano MT200 hydraulic disc, 160mm rotors
• Cranks: 3-piece tubular chromoly 8-spline, 170mm
• Bottom bracket: Sealed Mid, 19mm
• Pedals: Theory Outside nylon
• Chain: Theory 410
• Sprocket: Theory Legacy 6061-T6 aluminum, 32T
• Seat: Rixin Aspect railed
• Seat post: Alloy micro-adjust, 27.2 x 300mm
• Seat clamp: Alloy quick-release
• Front hub: Alloy low-flange sealed, 3/8" axle
• Rear hub: Theory Turnstyle alloy high-engagement disc cassette, sealed, 14mm axle
• Rear cog: 16T
• Rims: 6061 aluminum double-wall, 36H
• Tires: Street Level, 27.5 x 3.0"
• Bike weight: 33 lb 4 oz
